MCX-2 Multi-Coolant Exchange System
Part Number: 470 80030 00
FEATURES
- Versatile. Compatible with all coolant types for adaptability.
- Effective. Contains two 7.5 gal new coolant tanks and one 15 gal waste tank provides simple, rapid switching from one coolant to another.
- Automatic Pump Shut-Off. Allows technicians to multi-task.
- Drip-Proof Tank Connectors. Easy to disconnect and eliminate waste.
- Fast. Service times of 3 minutes for increased productivity.
- Visible Fluid Level Indicators. Aid in service accuracy.
- Easy To Read Gauges. Monitor system pressure and vacuum for increased safety.
- Convenient. Powered by 12V power supply clips.

MCX-2 Product Details
Additional Models
470 80031 00, MCX-2F Multi-Coolant Exchanger, MCX-2 w/ Flush By-Pass
MCX-2F Operation Manual [PDF; 890 KB]
Product Specifications
Adapters Step Adapters Universal; 2 sets; 1-1/4 in to 1-3/4 in range (3.2 cm to 4.4 cm) diameter (MCX-2HD contains additional step adapters) / Hose Adapters: Universal; 2 hoses, 1-1/4 in to 1-3/8 in (3.2 cm to 3.5 cm) and 1-1/2 in to 1-3/4 in. (3.8 cm to 4.4 cm) diameter (MCX-2HD contains additional adapter hoses)
Coolant Exchange 92 to 98% single pass, average exchange for most vehicles
Dimensions (H x W x D) 45 in x 38 in x 22.5 in (114 cm x 97 cm x 57 cm)
Fluid Tanks / Types Contains two 7.5 gal new coolant tanks; integrated output tube w/ debris filter screen and check valve; MCX-2HD contains two 15 gal (57 liter) new coolant tanks and one 15 gal waste coolant tank; integrated input/output tube; w/ automatic empty fluid level sensor
Hoses 3/8 in (9.5 mm); quick connect/disconnect (brass; chrome sleeve; silicone sealed) Operating Range 32° to 122°F (0° to 50°C)
Power Source 12 VDC - 15 Amp
Pressure Switch 6 to 12 psi (0.4 to 0.8 bar); protects vehicle cooling systems from high pressure
Process Time Less than 3 minutes average full exchange
Pumps 2 gal. (7.9 liter) per minute Fill: Diaphragm Type / Drain: Impeller Type
Warranty 1 Year–parts & labor
Weight 170 lb. (77 kg)
Recommended Accessories
370 80252 00 MCX Fill Tank, 7 gal. includes fitting, tube, filter, check valve
370 80204 00 MCX Waste Tank, 15 gal. includes fitting, float switch, auto shut-off
370 80019 00 Kit standard with MCX machines, hoses, adapters, hose clamps, wand
370 80033 00 MCX Flush Hose Assembly
Product Flyer & Operation Manual
MCX-2 Operation Manual [PDF; 772 KB]
MCX-2 Flyer [PDF; 1555 KB]
Videos
MCX-2HD Heavy Duty Multi-Coolant Exchange System
Part Number: 470 80032 00
FEATURES
- Heavy Duty. Includes HD Truck Adapter Set and 15 Gallon Tanks.
- Versatile. Compatible with all coolant types for adaptability.
- Effective. Contains two 7.5 gal new coolant tanks and one 15 gal waste tank provides simple, rapid switching from one coolant to another.
- Automatic Pump Shut-Off. Allows technicians to multi-task.
- Drip-Proof Tank Connectors. Easy to disconnect and eliminate waste.
- Fast. Service times of 3 minutes for increased productivity.
- Visible Fluid Level Indicators. Aid in service accuracy.
- Easy To Read Gauges. Monitor system pressure and vacuum for increased safety.
- Convenient. Powered by 12V power supply clips.

MCX-2HD Product Details
Product Specifications
Adapters Step Adapters Universal; 2 sets; 1-1/4 in to 1-3/4 in range (3.2 cm to 4.4 cm) diameter (MCX-2HD contains additional step adapters) / Hose Adapters: Universal; 2 hoses, 1-1/4 in to 1-3/8 in (3.2 cm to 3.5 cm) and 1-1/2 in to 1-3/4 in. (3.8 cm to 4.4 cm) diameter (MCX-2HD contains additional adapter hoses)
Coolant Exchange 92 to 98% single pass, average exchange for most vehicles
Dimensions (H x W x D) 45 in x 38 in x 22.5 in (114 cm x 97 cm x 57 cm)
Fluid Tanks / Types Contains two 7.5 gal new coolant tanks; integrated output tube w/ debris filter screen and check valve; MCX-2HD contains two 15 gal (57 liter) new coolant tanks and one 15 gal waste coolant tank; integrated input/output tube; w/ automatic empty fluid level sensor
Hoses 3/8 in (9.5 mm); quick connect/disconnect (brass; chrome sleeve; silicone sealed) Operating Range 32° to 122°F (0° to 50°C)
Power Source 12 VDC - 15 Amp
Pressure Switch 6 to 12 psi (0.4 to 0.8 bar); protects vehicle cooling systems from high pressure
Process Time Less than 3 minutes average full exchange
Pumps 2 gal. (7.9 liter) per minute Fill: Diaphragm Type / Drain: Impeller Type
Warranty 1 Year–parts & labor
Weight 170 lb. (77 kg)
Recommended Accessories
370 80252 00 MCX Fill Tank, 7 gal. includes fitting, tube, filter, check valve
370 80123 00 MCX Heavy Duty Adapter Kit
370 80204 00 MCX Waste Tank, 15 gal. includes fitting, float switch, auto shut-off
370 80019 00 Kit standard with MCX machines, hoses, adapters, hose clamps, wand
370 80033 00 MCX Flush Hose Assembly
Product Flyer & Operation Manual
MCX-2HD Operation Manual [PDF; 897 KB]
MCX-2HD Product Flyer [PDF; 1548 KB]
VCX-4 Vacuum Coolant Exchange Systems
Part Number: 470 80020 00
*See 'Additional Models' below for VCX-1
FEATURES
- Effective. Four transparent, large capacity cylinders; three for new coolant and one for waste.
- Color-Coded Function Valve. For easy control and operation.
- Adaptable. Easy coolant selection/changeover for flexible adaptation of most vehicles.
- Fast. Service cycles of 5-15 minutes for increased productivity.
- Vacuum Gauge. For complete exchange efficiency.
- Pressure Relief Valve. Located on waste fluid cylinder for increased safety.
- No-Leak End Cap Design. Reduces coolant waste.
- Convenient. Powered by shop air.

VCX-4 Product Details
Additional Models
470 80019 00, VCX-1 Vacuum Coolant Exchanger, Two Tube Design
VCX-1 Operation Manual [PDF; 533 KB]
Product Specifications
Adapters 2 Cone plugs; 8 in (20 cm) hose adapter
Controls Ball valves w/ color-match system
Coolant Cylinders 20 quart (18.9 liter) each
Dimensions (H x W x D)
- VCX-1: 63 in x 28 in x 22.5 in (160 cm x 71 cm x 57 cm)
- VCX-4: 63 in x 28 in x 29 in (160 cm x 71 cm x 74 cm)
Fluid Tanks / Types Any coolant type (Fast easy changeover)
Hoses Clear, wire reinforced 10 ft. (3 m)
New Fluid Pump Venturi vacuum generator; 28 inHg (0.95 bar) maximum
Power Source Shop air, 55 to 110 psi (3.8 to 7.6 bar)
Process Time 5 to 15 minutes average
Warranty 1 Year–parts & labor
Weight
- VCX-1: 166 lb. (75 kg)
- VCX-4: 200 lb. (91 kg)
Recommended Accessories
370 80071 00 VCX Adapter Kit, Consists of cone and hose
370 80095 00 VCX Adapter Kit, for Radiator Pressure Relief´
060 81215 00 VCX Adapter, Cone Plug
Flyer, Operation Manual & VCX Safety Information
VCX-1 & VCX-4 Flyer [PDF; 2127 KB]
VCX-4 Operation Manual [PDF; 1428 KB]
Safety Information for VCX Series [PDF; 133 KB]
Video
VCX-32HD Heavy Duty Coolant Exchange System
Part Number: 470 80033 00
FEATURES
- Fast. Easy to use.
- Clean. No need to handle fluid and includes drain bypass valve to avoid contaminated coolant from entering tank.
- Fully Pneumatic. Utilizes two hoses to connect to the top and bottom of a coolant system/radiator via quick connect fittings.
- Automatic Coolant Flow Stop. Ensures no air pockets in coolant system.
- Versatile. Can also be used to perform a coolant pressure or vacuum test, or coolant system flushes.
- Adapters. Available for various engines for both drain and fill.
- Sampling Capabilities. Samples can easily be taken during the drain process.

VCX-32HD Product Details
Product Specifications
Dimensions (H x W x D) 45 in x 26 in x 36 in (114 cm x 66 cm x 91 cm)
Weight 168 lb (76 kg)
Air Supply 125 PSIG
Tank Capacity 34 gal
Wheels 3 in front casters, 10 in semi-pneumatic rear tires
Hoses 15 ft on both vacuum, pressure hose and drain/fill hose
Filters 5 micron filter for refilling vehicles after coolant removal
Construction Powder coated, all steel
Warranty 1 Year
Flyer & Operation Manual
VCX-32HD Flyer [PDF; 265 KB]
VCX-32HD Operation Manual [PDF; 2706 KB]
