The patented Gray Wireless Portable Lift System improves a shop's safety, productivity and flexibility. The wireless lift system family will lift a wide variety of vehicles allowing technicians to safely and efficiently complete preventative maintenance tasks prior to major component repair.

FEATURES

  • Heavy Duty Lifting Capacity. 14,000 lb (CML-7) and 19,000 lb (CML-9) per column capacity options. Wide base available in 19,000 lb capacity (CML-9W).
  • Intelligent. Patented wireless smart lift technology.
  • Simple. Tablet-based touch screen with on-board manuals, videos and internet.
  • Broad Application. Heavy duty through light duty vehicles.
  • Fully Adjustable Carriage. 12" forks supports wheel diameter from 5" to 24.5"
  • Patent Pending. Down-stop visual safety system.
  • Adjustable. Lift height 69" (1753 mm)

Sold in sets of 2, 4, 6 or 8 allowing users a capacity range of 26,500 lbs to 148,000 lbs

CML-7

Wireless Mobile Column Lift

Model Number: CML-7 | Part Number: 485 80094 00

Additional Features

  • 24 volt mobile column, with a wide, adjustable carriage for over-sized tire engagement
  • Features the industry's original wireless communication system, state of the art touch screen graphic control system, and a patented self-centering adjustable carriage, providing the user with the most reliable and safe lifting environment
  • No external wires or cords providing clear and safe access to the undercarriage of the vehicle
  • When used at full operating height the user is provided with a lift height of 69 inches of free-and-clear access perfect for preventative maintenance; transmission removal and installation; clutch replacements; and with singe and paired operation make easy work of axle, brake, and wheel work

Specifications

Certification ALI Certified

Capacity (Each) 14,000 lb (6,350 kg)

Max. Hydraulic Operating Pressure 2,180 psi (15 MPa)

Min/Max Wheel Diameter 5 in / 24.5 in (127 mm / 622 mm)

Min (2)/Max (4) Lift Height 32 in / 69 in (813 mm / 1,753 mm)

Lift Speed (Max Load) 60 in/min (1,524 mm/min)

Weight 1,485 lb (674 kg)

Height 88.5 in (2,248 mm)

Height at Full Lift (157.13 in (3,991 mm)

Operating Peak Power 4 HP (3 kW)

Operating Voltage 24 VDC Nominal

Charger Voltage Required 70-130 VAC @50-60 Hz

Additional Sets

485 80095 00, CML-6W4 27 Ton Wireless Mobile Column Lift - Set of 4

485 80096 00, CML-6W6 40 Ton Wireless Mobile Column Lift - Set of 6

485 80097 00, CML-6W8 54 Ton Wireless Mobile Column Lift - Set of 8

CML-9

Wireless Mobile Column Lift

Model Number: CML-9 | Part Number: 485 80098 00

Additional Features

  • 24 volt mobile column, with a wide, adjustable carriage for over-sized tire engagement
  • Features the industry's original wireless communication system, state of the art touch screen graphic control system, and a patented self-centering adjustable carriage, providing the user with the most reliable and safe lifting environment
  • No external wires or cords providing clear and safe access to the undercarriage of the vehicle
  • When used at full operating height the user is provided with a lift height of 69 inches of free-and-clear access perfect for preventative maintenance; transmission removal and installation; clutch replacements; and with singe and paired operation make easy work of axle, brake, and wheel work

Specifications

Certification ALI Certified

Capacity (Each) 19,000 lb (8,165 kg)

Max. Hydraulic Operating Pressure 2,600 psi (17.9 MPa)

Min/Max Wheel Diameter 5 in / 24.5 in (127 mm / 622 mm)

Min (2)/Max (4) Lift Height 32 in / 69 in (813 mm / 1,753 mm)

Lift Speed (Max Load) 60 in/min (1,524 mm/min)

Weight 1,510 lb (685 kg)

Height 88.5 in (2,248 mm)

Height at Full Lift (157.13 in (3,991 mm)

Operating Peak Power 4 HP (3 kW)

Operating Voltage 24 VDC Nominal

Charger Voltage Required 70-130 VAC @50-60 Hz

Additional Sets

485 80099 00, CML-9W4 37 Ton Wireless Mobile Column Lift - Set of 4

485 80100 00, CML-6W6 55 Ton Wireless Mobile Column Lift - Set of 6

485 80101 00, CML-6W8 75 Ton Wireless Mobile Column Lift - Set of 8

CML-9W

Wireless Mobile Column Lift

Model Number: CML-9W | Part Number: 485 80102 00

Additional Features

  • 24 volt mobile column, with a wide, adjustable carriage for over-sized tire engagement
  • Features the industry's original wireless communication system, state of the art touch screen graphic control system, and a patented self-centering adjustable carriage, providing the user with the most reliable and safe lifting environment
  • No external wires or cords providing clear and safe access to the undercarriage of the vehicle
  • When used at full operating height the user is provided with a lift height of 69 inches of free-and-clear access perfect for preventative maintenance; transmission removal and installation; clutch replacements; and with singe and paired operation make easy work of axle, brake, and wheel work

Specifications

Certification ALI Certified

Capacity (Each) 19,000 lb (8,165 kg)

Max. Hydraulic Operating Pressure 2,600 psi (17.9 MPa)

Min/Max Wheel Diameter 4 in (102 mm) - No Max

Min (2)/Max (4) Lift Height 32 in / 69 in (813 mm / 1,753 mm)

Lift Speed (Max Load) 60 in/min (1,524 mm/min)

Weight 1,575 lb (714 kg)

Height 88.5 in (2,248 mm)

Height at Full Lift (157.13 in (3,991 mm)

Operating Peak Power 4 HP (3 kW)

Operating Voltage 24 VDC Nominal

Charger Voltage Required 70-130 VAC @50-60 Hz

Additional Sets

845 80103 00, CML-9WB4 37 Ton Wireless Mobile Column Lift with Wide Base - Set of 4

845 80104 00, CML-9WB6 55 Ton Wireless Mobile Column Lift with Wide Base - Set of 6

845 80105 00, CML-9WB8 74 Ton Wireless Mobile Column Lift with Wide Base - Set of 8
